180PCS Nylon Waterproof Electrical Cable Wire Splice Heat Shrink Wire Connector Marine Automotive Heat-Resistant Terminals Set
Détails sur le produit:
| Lieu d'origine: | Chine |
| Nom de marque: | QW |
| Numéro de modèle: | Bleu rouge jaune rose |
Conditions de paiement et expédition:
| Quantité de commande min: | 2 |
|---|
|
Détail Infomation |
|||
| Taper: | Couplée | Couleur: | Bleu rouge jaune rose |
|---|---|---|---|
| Matériel: | Nylon + en conserve | Certificat: | ISO9001 SGS CE CQC ROHS |
| Nom de produit: | Connecteurs de fils de joint de soudure | Fourchette: | 10-12 / 14-16 / 18-22 AWG |
| Emballer: | 180/200/210/220/240/250/270/480pcs / boîte | MOQ: | 1 boîte |
| Article: | Tubes de chaleur | Application: | Connexion de fil |
| Usage: | Câble de connexion | ||
| Mettre en évidence: | nylon waterproof wire connectors,heat shrink electrical terminals,marine automotive cable splice set |
||
Description de produit
| Property | Specification Requirement | Test Method | Typical Value |
| Tensile strength(Room temp.) | Min.10.4Mpa | UL224 | 17.2Mpa |
| Elongation at break(Room temp.) | Min.200% | UL224 | 280% |
| Tensile strength after aging(158℃ 168hrs) | Min.7.3Mpa | UL224 | 11.5Mpa |
| Elongation after aging(158℃ 168hrs) | Min.100% | UL224 | 200% |
| Voltage withstand(Uh-aged) | Withstand 2.5kv for 1 minute and breakdown | UL224 | pass |
| Voltage withstand(Aged) | Withstand at least half of un-aged breakdown voltage for 1 minute and breakdown |
UL224 | pass |
| Copper corrosion(158℃ 168hrs) | No corrosion of bare copper | UL224 | No sign of deg. |
| Copper stabiity(158℃ 168hrs) | No sign of degradation (min.elongation 100%) | UL224 | pass |
| Cold blend(-30℃ 1hrs) | No crack | UL224 | pass |
| Maximum secant modulus(2%) | 173Mpa | UL224 | pass |
| Volume resistivity | Min.1014Ω.m | UL224 | pass |
| Heat shock(250℃ 4hrs) | No crack | ASTM D2671 | pass |
| Dielectric strength | >15.8kv/mm | ASTM D2671 | >25kv/mm |
Company Information
Certifications
CNBX Insulated Heat Shrink Waterproof Electrical Terminal Solder Seal Wire Connector Crimping Set.Hampool 270pcs Marine wiring harness heat resistant Waterproof Heat Shrink Duraseal electric Wire Connectors Terminals Kit.480pc Insulated Waterproof Auto Terminal Set Heat Shrink Wire Connector kit
Vous voulez en savoir plus sur ce produit
